Impeller, Hayward Tristar, 0.5ohp/0.75thp, w/Screw : SPX3205C

Impeller, Hayward Tristar, 0.5ohp/0.75thp, w/Screw Hayward Pump Impeller Closed face impeller made for the TriStar SP3200/SP3200EE/SP3600 pool pump by Hayward. Rated at 1/2hp, it is used in a SP3200 and or SP3600 pump body, and must be installed on a 1/2hp (or greater) square flange motor. Shaft seal sold separately Impeller Type: Closed Face Impeller Diameter OD: 4-1/8" Vane Width ID: 3/16" Eye Diameter OD: 2-3/16" Eye Length: 1-1/16" Impeller Width OD: 9/16" Seal Seat Depth: 11/16"Shaft Length: Shaft Diameter OD: Seal Seat Diameter OD: 1-1/8"Manufacturer: HaywardPump Application: SP3200, SP3200EE, SP3600, Tristar Replaces 5112-210,610377006187,623878,HAY-101-3215,SP3205C,
